Revision sheet

Al-Ghorab open distal shunt for ischaemic priapism

8 steps, each one the authored title and caption from the interactive animation, with the frame captured from that step. Read it before the case, or print it and work through the steps in order.

Teaching only, not for diagnosis or treatment decisions. The text on this sheet is the animation's own step copy, reproduced verbatim.

Open the animation All revision sheets Download the PDF

UrOops3D · UroRef · © Nity G

  1. 01

    Refractory ischaemia

    Al-Ghorab open distal shunt for ischaemic priapism. Step 1: Refractory ischaemia. Captured frame from the interactive animation.
    • Dark, rigid corpora and a soft glans.
    • Ischaemia confirmed on corporal blood gas; aspiration, irrigation, phenylephrine and a percutaneous distal shunt have already failed.
    • The two healed puncture marks are the history.
  2. 02

    Tourniquet and set-up

    Al-Ghorab open distal shunt for ischaemic priapism. Step 2: Tourniquet and set-up. Captured frame from the interactive animation.
    • A tourniquet at the base keeps the field still during the excision.
    • A urethral catheter is optional and marks the urethra, which lies ventral to everything that follows.
  3. 03

    Transverse dorsal glans incision

    Al-Ghorab open distal shunt for ischaemic priapism. Step 3: Transverse dorsal glans incision. Captured frame from the interactive animation.
    • A transverse incision in the dorsum of the glans, distal to the corona, carried down to the tunica.
    • The lips part and the white dorsal tips of both corpora lie in the wound.
  4. 04

    Excise the first segment: patient's left

    Al-Ghorab open distal shunt for ischaemic priapism. Step 4: Excise the first segment: patient's left. Captured frame from the interactive animation.
    • Allis forceps on the dorsal tunica of the tip; a segment is excised with scissors.
    • Dark blood follows through a round window with a rim.
    • The excision is from the dorsal tip, away from the urethra.
  5. 05

    Excise the second segment: patient's right

    Al-Ghorab open distal shunt for ischaemic priapism. Step 5: Excise the second segment: patient's right. Captured frame from the interactive animation.
    • The same on the other corpus, to the same depth.
    • Two windows, one in each tip, with the septum intact between them.
  6. 06

    Evacuate: compression from base to tip

    Al-Ghorab open distal shunt for ischaemic priapism. Step 6: Evacuate: compression from base to tip. Captured frame from the interactive animation.
    • External pressure on the corpora from base to tip.
    • Dark clot and stagnant blood come out through the windows, then bright blood: restored inflow is the sign, not softening alone.
  7. 07

    Close the glans; tourniquet off

    Al-Ghorab open distal shunt for ischaemic priapism. Step 7: Close the glans; tourniquet off. Captured frame from the interactive animation.
    • The glans incision is closed with interrupted sutures over the open windows.
    • The tourniquet comes off.
    • The shunt is the open window under the closed glans: a drainage path from each corpus into the glans spongy tissue.
  8. 08

    Reassess and counsel

    Al-Ghorab open distal shunt for ischaemic priapism. Step 8: Reassess and counsel. Captured frame from the interactive animation.
    • A soft shaft and a dressing.
    • Firmness afterwards may be oedema or hyperaemia, so a repeat corporal blood gas decides.
    • Duration drives fibrosis; a prosthesis is discussed later in delayed or refractory cases.
